Geothermal Phenomena

4 min read

In places with high geothermal energy levels, the following phenomena can be observed:

Mammoth Hot Springs — a large complex of springs in Yellowstone National Park, USA. (Source: © IVÁN VIEITO GARCÍA /

Hot springs

with temperature often close to 100 °C. The hot water ascends from depths along fault lines.

Fumaroles of the El Tatio geothermal field, which has the highest elevation of all geothermal fields, at Atacama, Chile. (Source: © Nataliya Hora /


openings in the crust forcing out superheated steam and gases at temperatures between 200 and 800 °C. They are usually created by gases separated from hot magma.

A geyser in the Whakarewarewa geothermal region, in the middle of the North Island of New Zealand. (Source: © Tomtsya /


hot water with steam that is heated by magma in the deep and then erupts in sudden bursts to the surface.

The surroundings of a mud volcano with a bubbling mouth. (Source: © Fotokon /

Mud pots

hot springs with a high clay content.

Video: 3D model of volcanic activity. Due to the heat release which leads to a movement of molten material in the Earth’s body gets this material (magma) in some places to the Earth’s surface in the form of volcanic eruption.

Probably the most famous geyser in the world is Old Faithful in Yellowstone National Park in the USA.

The oldest still active geyser is the Castle in Yellowstone National Park. Judging by the geyserite sinter deposits, it may be well over 5,000 years old.

Bubbling water and steam rising in the mouth of a geyser in Yellowstone National Park, USA. (Source: © Pix by Marti /
21 pictures
A picturesque azure lake with hot water in the oldest national park in the USA, Yellowstone. (Source: © oldmn /
Countless beautiful displays of geothermal activity are found in Yellowstone National Park, USA. (Source: © PapiGau /
A mud cauldron with steam raising, Kamchatka, Russia. (Source: © Tatiana Grozetskaya /
21 pictures

Mysterious Bursting Spring

The Strokkur geyser in the Hvítá river region (Iceland) expels boiling water regularly, every 5—10 minutes. (Source: © Doin Oakenhelm /

The Strokkur geyser in the Hvítá river region (Iceland) expels boiling water regularly, every 5—10 minutes.

A geyser is a specific kind of spring that bursts out a mixture of water and steam in regular or irregular intervals, often as high as a few dozen meters. The term is derived from the Icelandic geyser named Geysir (geysa means to flow) and used to describe any similar formation. Several hundred geysers are known, mostly concentrated in five regions. The heat driving these geysers is magmatic.

A Geyser is basically a temporary geological formation that can form in a place where there is sufficiently porous bedrock, a rich source of water, a source of heat (e.g. magmatic) and a sufficiently watertight reservoir for the water to accumulate and heat up. Water enters the system through cracks in the Earth’s crust and it accumulates in the underground reservoir. The lower part of the reservoir is heated by hot rock or by magma to temperatures over the boiling point. Since the water is under great pressure from the surrounding rock and the hydraulic head over the reservoir, the water does not start to boil and remains liquid. Once the hot water ascends closer to the surface, where the pressure is not as high, or when the temperature simply reaches a critical limit, the superheated water violently changes into steam, which then occupies a volume 1,600 times larger than the volume of the water. The expanding steam then forces out the reservoir water above it to the surface. After that, the reservoir starts filling with colder water again preparing itself for the next eruption.

For a geyser to come into being, very specific hydrologic conditions are required, which mostly occur in volcanic regions. (Source: © VanderWolf Images /

For a geyser to come into being, very specific hydrologic conditions are required, which mostly occur in volcanic regions.

Several hundred active geysers are known. Most of them are concentrated in five regions. About half of them can be found in Yellowstone National Park (map) in the USA. The second largest geyser field is in the Geyser Valley in Russia on the Kamchatka peninsula (map). The remaining three important sites with high geyser concentrations are El Tatio in Chile (map), the Taupo Volcanic zone in New Zealand (map) and practically the whole island of Iceland (map).

A massive eruption of the Old Faithful Geyser in Yellowstone National Park, USA. (Source: © Steve Byland /
11 pictures
A geyser is awakening — the water is boiling and starting to rush to the surface. (Source: © Oleksandr Umanskyi /
The Lady Knox Geyser near the town of Rotorua (New Zealand) is usually set off every day at 10:15 by throwing in a bar of soap. (Source: © JanMika /
The highest cold geyser in the world, reaching as high as 64 meters, can be found near the town of Andernach, Germany. (Source: © chuckyyy /
11 pictures

The highest geyser in the world is the Steamboat in the USA. It can throw water over 90 meters high. Until 1904 the highest geyser was the Waimangu, which had some eruptions higher then 460 meters.
